USB Icon

Modified on: October 24,2008
Rating
Downloads: 1398
Comments
7

Specifications

Downloads:1398
Description:The USB Icon is embossed, in a recessed area, on the topside of the USB plug. This provides easy user recognition and facilitates alignment during the mating process. The USB Icon and Manufacturer’s logo should not project beyond the overmold surface. The USB Icon is required, while the Manufacturer’s logo is recommended, for both Series “A” and “B” (or “mini-B”) “B” plug assemblies. The USB Icon is also located adjacent to each receptacle. Receptacles should be oriented to allow the Icon on the plug to be visible during the mating process. Figure 6-6Figure 6-7 and Figure 6-8 illustrates the typical plug orientations.




Download the SOLIDWORKS Block.



(Login required)
