2D Blocks for SOLIDWORKS

Explore and download free 2D blocks for SOLIDWORKS that can be dragged and dropped into your SOLIDWORKS files to create schematics drawings, simulate mechanisms, and more.

A SOLIDWORKS 2D block is a 2D drawing item or sketch entity for use in SOLIDWORKS® 3D CAD software. You can make, save, edit, and insert blocks for drawing items and sketch entities that you use often, such as standard notes, title blocks, label positions, and more. You can attach blocks to geometry or to drawing views, and you can insert them into sheet formats.

3D ContentCentral® is a community of both users and suppliers. 2D Blocks are available on 3D ContentCentral for users of SOLIDWORKS® 3D CAD software along with millions of supplier parts and assemblies that have been certified by the manufacturers of these commercial, off-the-shelf components, SOLIDWORKS macros, and library features.

How does 3D ContentCentral work?

On 3D ContentCentral, you can perform any of the following tasks, thereby saving you precious design time that you would otherwise spend designing 2D or 3D CAD models of supplier components from 2D catalogs (PDF or DWG files):

  • Search for supplier components using part numbers, product names, descriptions, product parameters, and other application-specific criteria, or by simply browsing through an intuitive catalog interface. When you locate a component you want, request a quote from the supplier by simply submitting an RFQ (Request for Quotation) directly from the component page.
  • Configure components based on specific requirements, such as dimensions, features, colors, and accessories.
  • View free 2D and 3D parts & assemblies of both user-contributed and supplier components, 2D blocks, Library Features and Macros. You can zoom, pan, and rotate the parts & assemblies.
  • Download free 2D blocks, library features and macros for SOLIDWORKS. Download free 2D and 3D parts & assemblies in just seconds, in either native formats for several major mechanical CAD systems, including SOLIDWORKS® 3D CAD software, CATIA®, DraftSight, Pro/ENGINEER®, eDrawings®, and AutoCAD®, or industry standard CAD formats for Autodesk Inventor Series, Solid Edge, Unigraphics®, and other CAD systems.
  • Tag your favorite parts & assemblies, 2D blocks, library features, and macros with the keywords you use and then whenever you want them next simply search with your keywords.
  • Request specific parts & assemblies, 2D blocks, library features, and macros of the user community.
  • Personalize your own workspace on 3DCC and easily access your favorites, requests, gallery, comments, profile, downloads, and views.

2D Blocks for SOLIDWORKS Spotlight

Put yourself in the Spotlight!

The person with the greatest number of downloads in a category gets the spotlight. The more you contribute, the more likely you'll be in the spotlight.

Most Wanted Content

If you can't find something you need on 3DCC, request it.

Or, if someone requests something that you need, vote for it. More votes means more visibility, and more visibility increases the chances that someone will share it. And, when someone shares the item, you'll get an email letting you know.
